mounting clips MK1 for mounting the profiles on the wall. the clips, made of break-resistant polyoxymethylene, are mounted by simply screwing. if necessary, drilling and a dowel must be inserted. for a sufficiently stable installation, the clips should be attached at a distance of 40 to 50 cm.
Product:
SKU:
G50-13-DK-ELO
SKU: G50-13-DK-ELO
ID 2018: G0.2-A
height (a)
50,0 mm
width (b)
13,0 mm
length (l)
4,0 m
Endsurface EAS-G50-13-DK-ELO
perfect fit lasered endsurface EAS-G50-13-DK-ELO made of anodized aluminum for profile endings. the endsurface (coverplate) has to be glued on at the profile ending, which creates a clean finish. informations to install the endsurface can be found in the assembly instructions.
SKU:
EAS-G50-13-DK-ELO
Outside corner fitting AEF-G50-13-DK-ELO
prefabricated outside corner fitting AEF-G50-13-DK-ELO made of anodized aluminum with a lateral length of 245 x 245 mm, milled and unbent. the prefabricated fitting for outside corners makes it easier to create corners on site. the outside corner fittings simply need to be adjusted in length, bent and attached to the mounting clips.
SKU:
AEF-G50-13-DK-ELO
G50-13-DK-ELO-USSF-PVC3-detail-DE.pdf
G50-13-DK-ELO-USSF-PVC3-detail-DE.pdf
G50-13-DK-ELO-USSF-PVC3.dxf
G50-13-DK-ELO-USSF-PVC3.dxf
tender specifications :: baseboard :: G50-13-DK-ELO :: Microsoft Word :: (german language)
AT_G50-13-DK-ELO.docx
tender specifications :: baseboard :: G50-13-DK-ELO :: PDF :: (german language)
AT_G50-13-DK-ELO.pdf
tender specifications :: baseboard :: G50-13-DK-ELO :: GAEB x81 :: (german language)
AT_G50-13-DK-ELO.x81
assembly note :: baseboards :: G series :: (german language)
aluplan-montage-serie-G-DE.pdf
